Deep Steel Center also stands out as a reliable Stainless Steel 316Ti Sheets & Plates Stockists, offering a comprehensive range of products to meet the diverse requirements of various industries. Our inventory is meticulously managed to ensure that we can cater to both small and large-scale projects, providing a seamless supply experience for our customers. Our dedicated team of professionals is always ready to assist with any inquiries, ensuring that you receive the best possible service and support.
In addition to catering to the domestic market, Deep Steel Center has established itself as one of the prominent Stainless Steel 316Ti Sheets & Plates Exporters from Mumbai, India. Our high-quality products have gained international recognition, and we have built a strong network of clients across the globe. Our commitment to excellence and adherence to international standards has enabled us to export our products to various countries, meeting the stringent requirements of our global clientele.
Stainless Steel 316Ti Sheets & Plates Manufacturers in Mumbai, Stainless Steel 316Ti Sheets & Plates Suppliers in Mumbai, Stainless Steel 316Ti Sheets & Plates Stockists in Mumbai, Stainless Steel 316Ti Sheets & Plates Exporters in Mumbai
Choosing Deep Steel Center means opting for unparalleled quality, reliability, and customer-centric service. Our Stainless Steel 316Ti Sheets & Plates are designed to deliver superior performance and longevity, ensuring that your projects achieve the highest levels of success. With our extensive experience and expertise, we are well-equipped to meet the evolving needs of the market, providing innovative solutions and exceptional products.
Deep Steel Center is your go-to source for premium Stainless Steel 316Ti Sheets & Plates. As leading Stainless Steel 316Ti Sheets & Plates Manufacturers, Suppliers, Stockists, and Exporters in Mumbai, India, we are dedicated to providing top-quality products and exceptional service. Trust us to be your partner in achieving excellence with our superior stainless steel solutions.
316/316L/316Ti Stainless Steel Sheets & Plates Equivalent Grades
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 316 | S31600 | 1.4401 / 1.4436 | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | SUS 316 | 316S31 / 316S33 | - |
| SS 316L | S31603 | 1.4404 / 1.4435 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 |
| SS 316Ti | S31635 | 1.4571 | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 | SUS 316Ti | 904S13 | - |
Specification of Stainless Steel 316Ti Sheets & Plates
Stainless Steel Sheets & Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Chemical Composition of Stainless Steel 316Ti Sheets & Plates
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|
| 316 (S31600) |
0.08 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316L (S31603) |
0.03 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316TI(S31635) | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.1 |
Mechanical Properties Of Stainless Steel 316Ti Sheets & Plates
| Grade | Tensile Strength ksi (min) |
Yield Strength 0.2% ksi (min) |
Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 316 (S31600) |
75 | 30 | 40 | 217 | 95 |
| 316L (S31603) |
70 | 25 | 40 | 217 | 95 |
| 316TI(S31635) | 515(Mpa) | 205(Mpa) | 35 | 205 | 75 |
Physical Properties of 316/316L/316Ti Stainless Steel Round Bar
| SS 316/316L | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 316Ti | ||||||
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
| SS 316/316L/316Ti | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 | Melting Point (°F) | |||||
| 8.0 g/cm3 | 1454 °C (2650 °F) | |||||
