Our large distribution network ensures that you always receive your orders on time. Thanks to our commitment to excellence, we have successfully become the trusted name and the first and foremost choice for innumerable businesses belonging to different sectors for their high-quality and reliable stainless solutions.
Along with being one of the leading manufacturers and suppliers, Deep Steel Center is the preeminent Stainless Steel 304 Sheets & Plates Stockist in Mumbai, India. We have a stock of the full range of products with grades and specifications that suit varying requirements. We have departmental warehouses that are equipped with plants of technological innovation to store products in prime conditions, conserving their quality and readiness to be dispatched.
We are also deemed as leading Stainless Steel 304 Sheets & Plates Exporters because of our superfluity reputation along national perimeters. Deep Steel Center has been able to establish a strong commercial business ring in the non-native commerce as it has been exporting top-class stainless steel sheets and plates to various geographical locations of the world. Our export consistencies have also evolved while producing timeliness, accuracy, and in compliance with international trading standards due to which it is assured that our global practice gets their shipments in perfect condition up to the designated time scale.
Stainless Steel 304 Sheets & Plates Manufacturers in Mumbai, Stainless Steel 304 Sheets & Plates Suppliers in Mumbai, Stainless Steel 304 Sheets & Plates Stockists in Mumbai, Stainless Steel 304 Sheets & Plates Exporters in Mumbai
Deep Steel Center is located at Mumbai, India. We have set core values that represent our commitment towards serving our clients with integrity and excellence. Our Stainless Steel 304 Sheets & Plates are designed in such a manner so as to offer maximum utility, robustness, and performance to meet up with the challenging demands of the modern industrial sector. We take proud in being customer-centric in approach, offering tailormade solutions that cater to the needs of our clients. When you choose Deep Steel Center, you are selecting unmatched quality, reliability, and exceptional service in the world of stainless steel.
In essence, the best choice for superior Stainless Steel 304 Sheets & Plates is Deep Steel Center. Whether you are a manufacturer, supplier, stockist, or exporter, we have just the right solutions for you. So, contact us today and get to know how our products can take the good work of your projects to new heights of excellence.
304/304L/304H Stainless Steel Sheets & Plates Equivalent Grades
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
| SS 304H | S30409 | 1.4301 | - | - | - | - | - |
Specification of Stainless Steel 304 Sheets & Plates
Stainless Steel Sheets & Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Chemical Composition of Stainless Steel 304 Sheets & Plates
| C | Mn | Si | P | S | Cr | Ni | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304L | 0.03max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 12.0 | 0.10 max |
| 304H | min: 18.0 max:20.0 |
min: 8.0 max: 10.5 |
min: 0.04 max:0.10 |
0.75 max |
2.0 max |
0.045 max |
0.03 max |
0.10 max |
Mechanical Properties Of Stainless Steel 304 Sheets & Plates
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304L | 70 | 25 | 40 | 201 | 92 |
| 304H | 75 | 30 | 40 | 201 | 92 |
Physical Properties of 304/304L/304H Stainless Steel Round Bar
| SS 304/304L | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 304H | ||||||
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
