That is why Deep Steel Center also claims to be among the best Exporters of Stainless Steel 316 Sheets & Plates. The mature policies and strong determinations in quality and customer satisfaction contribute to the reputable position among the international markets. We supply our superior quality Stainless Steel 316 Sheets & Plates to many countries with international standards and accreditation. Our work is as packaged as carefully as they possibly can be so as not to get ruined while in transit to the clients.
If ever you want to find a competent supplier in Stainless Steel 316 Sheets & Plates in the industry Deep Steel Center is the answer. We have professionals with enough training to ensure that customers get the right products as they consult us throughout the process. Being one of the leading Stainless Steel 316 Sheets & Plates Suppliers and Stallion, we provide the best price in the market along with the same quality.
Stainless Steel 316 Sheets & Plates Manufacturers in Mumbai, Stainless Steel 316 Sheets & Plates Suppliers in Mumbai, Stainless Steel 316 Sheets & Plates Stockists in Mumbai, Stainless Steel 316 Sheets & Plates Exporters in Mumbai
Thus, Deep Steel Center is here to fulfill your all the requirements for SS 316 Sheets & Plates. Regardless of the fact whether you are searching for a manufactures, supplier or stockist or exporter of automobile spare parts in Mumbai, India, we have everything in store for you. These core values are among the reasons why we are at the top in the record of the best companies in the market. Everyone should visit Deep Steel Center for all your stainless steel requirements and feel the difference.
316/316L/316Ti Stainless Steel Sheets & Plates Equivalent Grades
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 316 | S31600 | 1.4401 / 1.4436 | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | SUS 316 | 316S31 / 316S33 | - |
| SS 316L | S31603 | 1.4404 / 1.4435 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 |
| SS 316Ti | S31635 | 1.4571 | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 | SUS 316Ti | 904S13 | - |
Specification of Stainless Steel 316 Sheets & Plates
Stainless Steel Sheets & Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Chemical Composition of Stainless Steel 316 Sheets & Plates
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|
| 316 (S31600) |
0.08 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316L (S31603) |
0.03 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316TI(S31635) | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.1 |
Mechanical Properties Of Stainless Steel 316 Sheets & Plates
| Grade | Tensile Strength ksi (min) |
Yield Strength 0.2% ksi (min) |
Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 316 (S31600) |
75 | 30 | 40 | 217 | 95 |
| 316L (S31603) |
70 | 25 | 40 | 217 | 95 |
| 316TI(S31635) | 515(Mpa) | 205(Mpa) | 35 | 205 | 75 |
Physical Properties of 316/316L/316Ti Stainless Steel Round Bar
| SS 316/316L | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 316Ti | ||||||
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
| SS 316/316L/316Ti | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 | Melting Point (°F) | |||||
| 8.0 g/cm3 | 1454 °C (2650 °F) | |||||
