As trusted Stainless Steel 304L Sheets & Plates Stockists, we understand the diverse needs of our clients and strive to meet them with precision. For precision management, we maintain an inventory that allows us to offer different sizes, thicknesses, and finishes of stainless steel sheets and plates. This therefore allows the clients to pick specifications best suiting their project requirements, and, in this regard, allowing flexibility and convenience.
Another area where Deep Steel Center has made the mark is the supply of Stainless Steel 304L Sheets & Plates Exporters. Our products are in great demand not only within the terrains of India, but are also appreciated in the strong numbers all over the international markets. We follow international standards and export regulations to indulge in the decoration and trust of the products throughout the world. All our export servicing is customized to be smooth and quick, bypassing delays that might likely occur and ensuring that our foreign clients receive their products at the right time.
Located in Mumbai, India, Deep Steel Centre is ideally located for effective service delivery towards both domestic and overseas markets. This fully integrated state-of-the-art manufacturing facility is complemented by an enviable workforce to produce and supply products of distinction to meet the exact needs of our clients. We proudly provide tailor-made solutions in catering to the unique requirements of a particular project, while following exactly to industry standards.
Stainless Steel 304L Sheets & Plates Manufacturers in Mumbai, Stainless Steel 304L Sheets & Plates Suppliers in Mumbai, Stainless Steel 304L Sheets & Plates Stockists in Mumbai, Stainless Steel 304L Sheets & Plates Exporters in Mumbai
Last but not least, Deep Steel Center is a name that pioneered the stainless industry as leading innovators in the manufacturing and supplying of Stainless Steel 304L Sheets & Plates. Our commitment to quality, reliability, and customer service is a powerful drive, branding us as the obvious choice of many clients from this subcontinent and around the exploration. Whether you need a trusted manufacturer, reliable supplier, a well-stocked stockist, or an efficient exporter, Deep Steel Center is indeed your partner to go-to for all your stainless steel needs.
304/304L/304H Stainless Steel Sheets & Plates Equivalent Grades
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
| SS 304H | S30409 | 1.4301 | - | - | - | - | - |
Specification of Stainless Steel 304L Sheets & Plates
Stainless Steel Sheets & Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Chemical Composition of Stainless Steel 304L Sheets & Plates
| C | Mn | Si | P | S | Cr | Ni | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304L | 0.03max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 12.0 | 0.10 max |
| 304H | min: 18.0 max:20.0 |
min: 8.0 max: 10.5 |
min: 0.04 max:0.10 |
0.75 max |
2.0 max |
0.045 max |
0.03 max |
0.10 max |
Mechanical Properties Of Stainless Steel 304L Sheets & Plates
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304L | 70 | 25 | 40 | 201 | 92 |
| 304H | 75 | 30 | 40 | 201 | 92 |
Physical Properties of 304/304L/304H Stainless Steel Round Bar
| SS 304/304L | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 304H | ||||||
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
