We are also proud to be one of the most trusted Stainless Steel 304H Sheets & Plates Stockists. With our ultra-modern storage facilities, our products are maintained under optimum conditions and ready for immediate dispatch. Well-managed stocks are maintained to ensure minimum delivery times, and thus we entertain every order of customers well within the stipulated time frame without compromising on quality.
Deep Steel Center is a key player in the global market as an exporter of Stainless Steel 304H Sheets & Plates. Our clients across the globe have great acceptance of our products with a feel-good factor about the satisfactory level of quality and economical prices. We realize the critical importance of timely delivery and sturdy packaging to ensure products reach our global clients in intact conditions.
Located in Mumbai, India, Deep Steel Centre is ideally located for effective service delivery towards both domestic and overseas markets. This fully integrated state-of-the-art manufacturing facility is complemented by an enviable workforce to produce and supply products of distinction to meet the exact needs of our clients. We proudly provide tailor-made solutions in catering to the unique requirements of a particular project, while following exactly to industry standards.
Stainless Steel 304H Sheets & Plates Manufacturers in Mumbai, Stainless Steel 304H Sheets & Plates Suppliers in Mumbai, Stainless Steel 304H Sheets & Plates Stockists in Mumbai, Stainless Steel 304H Sheets & Plates Exporters in Mumbai
Based in Mumbai, Deep Steel Center is committed to maintaining the first-rate nature in Stainless Steel 304H Sheets & Plates superior appreciation levels. Our circle of experienced persons is always ready to help you pick the best commodities based on all your specific requests. Deep Steel Center is the name for all your Stainless Steel 304H Sheets & Plates needs. Experience the difference when you deal with quality and expertise.
304/304L/304H Stainless Steel Sheets & Plates Equivalent Grades
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
| SS 304H | S30409 | 1.4301 | - | - | - | - | - |
Specification of Stainless Steel 304H Sheets & Plates
Stainless Steel Sheets & Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Chemical Composition of Stainless Steel 304H Sheets & Plates
| C | Mn | Si | P | S | Cr | Ni | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304L | 0.03max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 12.0 | 0.10 max |
| 304H | min: 18.0 max:20.0 |
min: 8.0 max: 10.5 |
min: 0.04 max:0.10 |
0.75 max |
2.0 max |
0.045 max |
0.03 max |
0.10 max |
Mechanical Properties Of Stainless Steel 304H Sheets & Plates
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304L | 70 | 25 | 40 | 201 | 92 |
| 304H | 75 | 30 | 40 | 201 | 92 |
Physical Properties of 304/304L/304H Stainless Steel Round Bar
| SS 304/304L | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 304H | ||||||
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
