SMO 254 Pipes and fittings
- SMO 254 Pipes and fittings
- Sanicro 28 Pipes and fittings
- 253 MA [S30815] Pipes
- 15‐5 PH Pipes and fittings
- 17‐4 PH Pipes and fittings
- Nitronic 50-60 Pipes and fittings
- A286
Products
QUICK ENQUIRY
We at Deep Steel Centre have dependably featured serving premium things, client-driven help, a speedy vehicle strategy, and complete help to our regarded clients. We are continually going the extra mile for our clients to satisfy their necessities. Being an ISO company, (Deep Steel Centre) promises quality and relentlessness at each step. We are a maker, provider, and exporter of ASTM SA 403, which is added with molybdenum, giving it favored control over traverse breaking down in halide-containing conditions similar to seawater, pound and variety plants, cruel waters, and so forth. A yield strength of 44 ksi and a rigid nature of 94 ksi, with a correspondingly high influence sturdiness, enable UNS to work in high-temperature adventures, similar to oil and designed creation. These fittings are known for working at a raised temperature without misshaping or checking.
SMO 254 Pipes and Fittings Manufacturers, SMO 254 Pipes and Fittings Suppliers, SMO 254 Pipes and Fittings Stockists, SMO 254 Pipes and Fittings Exporters
SMO 254 Pipes and Fittings Manufacturers in India, SMO 254 Pipes and Fittings Suppliers in India, SMO 254 Pipes and Fittings Stockists in India, SMO 254 Pipes and Fittings Exporters in India
Standard Specification For SMO 254 ASTM A182 Forged Pipe Fittings
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
SMO 254 Pipes and Fittings Manufacturers in Mumbai, SMO 254 Pipes and Fittings Suppliers in Mumbai, SMO 254 Pipes and Fittings Stockists in Mumbai, SMO 254 Pipes and Fittings Exporters in Mumbai
ASTM A182 SMO 254 Forged Fittings
Threaded and Socket Weld Pipe Fittings
| Products | Size | |
|---|---|---|
| ASTM A182 SMO 254 90° Elbows | ASTM A182 SMO 254 45° Elbows | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A182 SMO 254 Forged Caps | ASTM A182 SMO 254 Couplings | |
| ASTM A182 SMO 254 Forged Tees | ASTM A182 SMO 254 Unions | |
| ASTM A182 SMO 254 Forged Cross | ASTM A182 SMO 254 Inserts | |
| ASTM A182 SMO 254 Forged Plug | ASTM A182 SMO 254 Street Elbows | |
| ASTM A182 SMO 254 Bushings | ASTM A182 SMO 254 Pipe Nipple | |
SMO 254 Forged Fittings Standards / Types And Pressure Class :
| ASTM A182 - ASME SA182 | Standard Specification for SMO 254 Piping Fittings |
|---|---|
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
ASME SB403 SMO 254 Forged Fittings Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | SIS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SMO 254 | 1.4547 | S31254 | - | 2378 | - | Z1 CNDU 20.18.06Az | X1CrNiMoCuN20-18-7 |
Chemical Composition of Grade SMO 254 High Pressure Fittings
| Grade | % | Ni | Cr | Mo | Cu | N | C | Mn | Si | P | S |
| SMO 254 | Min. | 17.5 | 19.5 | 6 | 0.5 | 0.18 | - | - | - | - | - |
| Max. | 18.5 | 20.5 | 6.5 | 1 | 0.22 | 0.02 | 1 | 0.8 | 0.03 | 0.01 |
Mechanical Properties of ASTM B403 SMO 254 Forged Pipe Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| SMO 254 | 8.0 g/cm3 | 1320-1390 ℃ | 650 | 300 | 35 % |
ASTM B403 SMO 254 Forged Fittings Available Types
| SMO 254 Forged Pipe Fittings | SMO 254 High Pressure Forged Fittings |
|---|---|
| 254 SMO Socket Weld Fittings | SMO 254 Threaded Fittings |
| SMO UNS S31254 Socket Weld 90 Deg Elbow | 254 SMO Threaded 90 Deg Elbow |
| SMO 254 Socket Weld 45 Degree Elbow Suppliers | ANSI SMO 254 Screwed 45 Degree Elbow |
| SMO 254 Forged Tee Dealer | 254 SMO Threaded Tee Exporter |
| SMO DIN 1.4547 Socket Weld Cross Stockholder | SMO 254 Threaded / Screwed Cross Distributors |
| SMO 254 Socket Weld Half Coupling | SMO 254 Threaded Half Coupling Manufacturer |
| SMO 254 / 6Mo Full Coupling | SMO 254 / 6 Mo Coupling |
| SMO 254 Socket Weld Cap | SMO 254 / 6 Mo Screwed Cap |
| ANSI B16.11 SMO 254 Socket Weld Union | SMO 254 Threaded / Screwed Union Stockist |
| ASTM A182 SMO 254 Screwed Hex Plug | ASME SA182 SMO 254 Square Plug |
| SMO 254 Reducing Tee | SMO 254 Threaded / Screwed Bushing |
| A182 SMO 254 Hex Nipples | ASME SA182M SMO 254 Swage Nipple |
| 254 SMO Threaded Street Elbow | SMO 254 Threaded / Screwed Pipe Nipple |
| SMO 254 Socket weld Unequal Tee | SMO 254 ASME B16.11 Threaded Unequal Tee |
