Sanicro 28 Sheets and Plates are appropriate for the utilization in a large number of the enterprises and general works like oil and gas treatment facilities, power ages, water and gas pipeline, oil treatment facilities, substance plants, modern hardware, and atomic, warm and sun oriented power plants. Additionally, these are pertinent in the petrochemical business, drug industry, seawater hardware, drug gear, substance hardware, paper industry, heat exchanger and condensers too.
Sanicro 28 Sheets and Plates are made with the intensity therapy and welding process for better maintainability in antagonistic conditions. These sheets and plates are best for use in substance and food handling businesses. These items are safe from the pitting erosion, influence consumption, cleft erosion, and stress hole consumption too. For the most part, these items have great characteristics like welding, usefulness, machinability, formability, and longer assistance life in compound conditions.
These items need to go through a large number of the tests after the creation structure the ventures, for example, mechanical test, substance test, hardness test, influence erosion test, PMI test, ultrasonic test, hydrostatic test, full scale test, miniature test, and erupting test too.
Sanicro 28 Sheets and Plates Manufacturers in Mumbai, Sanicro 28 Sheets and Plates Suppliers in Mumbai, Sanicro 28 Sheets and Plates Stcokists in Mumbai, Sanicro 28 Sheets and Plates Exporters in Mumbai
Alloy 28 Sheets and Plates Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | EN |
|---|---|---|---|
| Sanicro 28® | 1.4563 | N08028 | X1NiCrMoCuN31-27-4 |
Specification of Sanicro 28 Sheets and Plates
Sanicro 28 Sheets and Plates Specification : ASTM B709 / ASME SB709
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Chemical Composition of Sanicro 28 Sheets and Plates
| Grade | C % | Si ≤ % | Mn ≤ % | P ≤ % | S ≤ % | Cr % | Mo % | Ni % | N % | Cu % |
|---|---|---|---|---|---|---|---|---|---|---|
| Sanicro® 28 | ≤ 0.02 | 0.70 | 2.00 | 0.03 | 0.01 | 26.0-28.0 | 3.00-4.00 | 30.0-32.0 | ≤ 0.11 | 0.70-1.50 |
Mechanical Properties Of Sanicro 28 Sheets and Plates
| Tensile strength Rm N/mm² |
0.2% Yield strength Rp ≥ N/mm² |
Elongation A5 ≥ % |
Hardness HB 30 ≤ HB |
Modulus of elasticity kN/mm² |
|---|---|---|---|---|
| 500-750 | 220 | 35/30 | 230 | 195 |
